PJM Dynamic Modeling and Interconnection: The Complete Generator Owner Guide

PJM Dynamic Interconnection, the world’s largest competitive electricity market serving 65 million people across 13 states and Washington DC, operates one of the most technically rigorous generator interconnection processes in North America.

For renewable energy developers and generator owners seeking to connect to the PJM grid, understanding PJM’s dynamic modeling requirements and interconnection process is essential for project success and timeline management.

PJM Manual 14G: The Interconnection Bible

PJM Manual 14G Generator Interconnection Facility Study Agreements is the primary governing document for generator interconnection in the PJM territory. It defines the technical requirements, study process, milestones, and documentation obligations for new generating facilities seeking interconnection to the PJM transmission system.

Key provisions of PJM Manual 14G relevant to generator owners include:

Queue Position and Deposit Requirements: PJM’s interconnection queue is managed through a cluster study process (the Reliability Transmission Expansion Planning, or RTEP, process). New applicants must submit required deposits and documentation to secure a queue position. The order of queue position significantly affects cost allocation for required network upgrades.

Dynamic Model Submission Requirements: All generators interconnecting to PJM must submit dynamic simulation models meeting PJM’s model data requirements. For IBRs, this includes both positive-sequence phasor models (for PSS/E) and electromagnetic transient models (for PSCAD-based studies in areas of high IBR penetration).

Technical Requirements at the POI: PJM specifies technical requirements for reactive capability, ride-through performance, and frequency response that must be met by all new generators. These requirements align with but may exceed baseline NERC standards in some areas.

PJM’s Dynamic Model Development Guidelines (DMDG)

The PJM Dynamic Model Development Guidelines (DMDG) document provides detailed specifications for the generator models that must be submitted as part of the interconnection process. Key DMDG requirements include:

Required Model Types:

• Generator electrical model (GENROU, GENSAL, REGCA1, or equivalent)
• Excitation system or reactive power control model (EXAC1, REEC_A, REEC_C, etc.)
• Turbine/governor model for synchronous generators
• Plant-level control models (REPC_A, REPC_D for IBRs)

Model Initialization Requirements: Models must initialize from a power flow base case without unacceptable transients. This requires careful coordination between load flow model development and dynamic model development.

WECC Model Compatibility: PJM uses the WECC-developed standard model library for most IBR applications. Generator owners should confirm that their inverter OEM’s models are compatible with WECC standard models or provide equivalent user-defined models.

Generic vs. Manufacturer-Specific Models: PJM accepts both WECC generic models (which are publicly available but less accurate for specific equipment) and manufacturer-specific models (which are more accurate but may be proprietary).

Our power system studies team has experience with both approaches and can advise on the optimal strategy for your project.

PJM RTEP: Understanding the Transmission Expansion Planning Process

The PJM Regional Transmission Expansion Plan (RTEP) is PJM’s annual process for identifying and approving transmission expansion projects needed to maintain reliability and accommodate new generation. Understanding how the RTEP process works is critical for generator owners because:

Network Upgrade Costs: New generation interconnections that cause thermal overloads or voltage violations on the existing transmission system trigger network upgrade requirements. These upgrades are typically allocated to the generator owner (for facilities in the generator’s Direct Connection Facilities) or to the general transmission system upgrade process (for broader network improvements).

RTEP Study Timeline: RTEP studies are conducted on a defined annual cycle, and the timing of your interconnection application relative to the RTEP cycle can significantly affect your study timeline and cost estimates.

Affected Facilities Studies: Large new generation projects may require detailed Affected Facilities Studies to quantify the transmission impacts of the project and identify required upgrades.

Financial Modeling for PJM Transmission Projects

For transmission owners and developers participating in PJM’s competitive transmission process, financial modeling of PJM transmission projects requires understanding:

• Cost allocation under FERC Order 1000: How transmission upgrade costs are allocated between benefiting transmission zones
• ATSI and RECO cost allocation zones: The specific PJM transmission cost allocation zones that affect project economics
• Incremental revenue from congestion relief: The economic benefit of transmission upgrades from congestion relief and energy cost reduction in downstream load zones

Our engineering team provides technical support for PJM transmission project development, including technical feasibility studies, model development, and regulatory filing support.

Utility-Scale Solar and Wind Interconnection in PJM

PJM’s interconnection queue contains thousands of proposed solar, wind, and battery storage projects. Navigating this complex process successfully requires:

Early Engineering Engagement: Begin dynamic model development and reactive capability documentation before submitting the interconnection request to avoid delays in the study process.

Understanding PJM’s Cluster Study Process: PJM studies interconnection requests in clusters, meaning your project’s study results may be affected by other projects in the same cluster. Understanding the cluster process helps manage expectations and plan contingencies.

Proactive Cost Estimate Management: Network upgrade cost estimates from PJM feasibility studies can be order-of-magnitude estimates with wide uncertainty ranges. Engaging your engineering team to independently validate PJM’s upgrade scope and cost estimates can identify opportunities to reduce costs through alternative technical approaches.

Final Thoughts

PJM’s interconnection process rewards preparation. The technical bar set by Manual 14G and the Dynamic Model Development Guidelines is high by design, reflecting the reliability demands of a grid serving 65 million people but it’s also predictable. Projects that arrive with complete, standards-compliant dynamic models, realistic reactive capability documentation, and a clear understanding of the RTEP cost allocation process consistently move through the queue with fewer restudies and fewer surprises.

The projects that stall are rarely stalled by bad luck. They’re stalled by avoidable issues: unsupported model types, momentary cessation left unaddressed, or cost assumptions that were never independently checked. None of that is a reason to delay entering the queue it’s a reason to bring the right engineering support to the table from day one.

FAQs

How long does the PJM interconnection process take for a utility-scale solar or wind project?

Timelines vary by queue cycle and study phase, but under PJM’s reformed “Cycle” process, a project entering the queue can expect to move through Phase I (feasibility), Phase II (system impact), and Phase III (facilities study) over roughly 2–3 years before reaching a Generator Interconnection Agreement, assuming no major restudies are triggered. Submitting a complete, study-ready modeling package at application avoids the most common source of delay: data requests due to incomplete or non-compliant dynamic models.

What dynamic simulation software does PJM require?

PJM standardizes on Siemens PTI PSS/E for positive-sequence phasor modeling, with the specific version tied to each queue cycle (for example, TC2-era studies used PSS/E v35.3.2). For projects in areas of high inverter-based resource (IBR) penetration, PJM additionally requires PSCAD-based electromagnetic transient (EMT) models, typically submitted at Decision Point II.

What happens if my dynamic model doesn’t pass PJM’s validation checks?

A failed or incomplete model submission generates a data request back to the generator owner, which restarts part of the review clock and can push your project into a later study cycle. Common rejection reasons include unsupported model types (PJM does not accept models like REECB1 or GAST), missing plant-level controller data, and models that fail to initialize cleanly from the power flow base case without transients.

What is “momentary cessation” and why does PJM care about it?

Momentary cessation is a temporary halt in current injection from an inverter-based resource during abnormal voltage conditions. PJM recommends eliminating this behavior in submitted models because it can worsen system-wide voltage recovery during disturbances. Reviewers specifically check REGC and REEC module parameters (such as low-voltage power logic and voltage-dependent limit settings) to confirm MC has been addressed.

Do I need a manufacturer-specific model, or is a generic WECC model good enough?

Either can be accepted, but they carry different tradeoffs. WECC generic models are publicly available and simpler to submit, but they’re less precise for your specific inverter hardware. Manufacturer-specific models better represent actual equipment behavior but may involve proprietary data-sharing agreements with your OEM. The right choice often depends on your project’s queue position, timeline pressure, and how much scrutiny your study is likely to receive.

Who typically pays for network upgrades identified in the interconnection study?

Cost responsibility depends on where the upgrade sits. Upgrades within your Direct Connection Facilities are generally allocated to your project, while broader network reinforcements identified through the RTEP process may be shared more widely under FERC Order 1000 cost allocation rules. Because feasibility-stage cost estimates can carry wide uncertainty bands, many developers commission an independent review of PJM’s assumptions before committing to a cost allocation.

Can PJM’s cost estimates or study results change between phases?

Yes. Because PJM studies queue positions as clusters, results depend on which other projects remain active in that cluster. If a competing project ahead of you in the queue withdraws or changes scope between Phase I and Phase II, your network upgrade requirements and cost estimates can shift meaningfully. This is a known risk across ISOs and RTOs, not unique to PJM, and it’s a key reason developers should treat early cost estimates as directional rather than final.

Our POI interconnection engineering services provide comprehensive support for PJM generator interconnection, from feasibility through commissioning. We also support utility-scale solar, wind, and BESS project development throughout the PJM footprint.
